Gas and Diesel Engine Compressors


Download Brochure Download Printable Brochure


These R-Series reciprocation two-stage air compressors feature a rugged cast iron crankcase and cast iron lined domed cylinders that eliminate head gasket concerns while improving compressor efficiency.


These R-Series reciprocation two-stage air compressors feature a rugged cast iron crankcase and cast iron lined domed cylinders that eliminate head gasket concerns while improving compressor efficiency.

Gas and Diesel Engine Screw Compressors
Model Engine Type & HP CFM PSI Dimensions Weight (lbs.)
RS18GEC30H-NK30 Kohler--18 38 175 40LX24WX42H 415
RS18GECBM-NK30 Kohler--18 38 175 40LX24WX28H 385
RS18GEH30H-NK30 Honda--18 18 175 40LX24WX42H 415
RS18GEHBM-NK30 Honda--18 18 175 40LX24WX28H 385
SGD-70 Kohler--25 70 100 40LX24WX44H 490
RS10GEH30H-NK30 Lombordini--10 17 175 40LX24WX42H 425
RS10GEHBM-NK30 Lombordini--10 17 175 40LX24WX28H 395
RS19GEH30H-NK30 Hatz--19.9 35 175 40LX24WX46H 455
RS19GEHBM-NK30 Hatz--19.9 35 175 40LX24WX32H 415
